23cm 1296 MHz 36 Element, Low Noise Super Yagi Competition and EME Antenna PA1296-36-3BUT

$325.00

Shipping time: 10 day(s)

Description

23cm 36 Element Competition and EME Super Yagi Antenna PA1296-36-3BUT

Super high gain 23cm Yagi. 20.4dBi

Now holds the current VK National record on 1296 at 2458 km.

Wideband operation 1290 - 1310 MHz.


Electrical Specifications


Frequency Range: 1290 - 1310 MHz

Free Space Forward Gain: 20.4 dBi

Front to Back Ratio: 32 dB

3 dB Horizontal Beamwidth: 18°3 dB

Vertical Beamwidth: 18.4°

Polarization: Horizontal

Nominal Input Impedance :50 Ohms

SWR Across Entire Band: < 1.2

Maximum Power Input: 300 W

Matching Method: Voltage balun. UT141 or similar Teflon cable

Connector: "N"


Mechanical Specifications


Number of Elements: 36

Element Diameter: 4 mm Aluminum rod

Dipole Diameter: 3 mm Copper

Longest Element: 120 mm

Element Mounting Position: Above the Boom

Balun and Connector: Included

Boom Length: 2.92 m

Boom Size: 20 x 20 mm

Number of Boom Pieces: 2

Guy rope support: No

Mounting Mast Diameter: 32 - 50 mm 1" - 1-1/2"

Survival Wind Speed: 120 km/h

Net Weight: 1.75 kg

Gross Weight: 3.65 kg

Transportation Length: 1.5 m


More about stacking is here.
